HG Series

As a market leader in the sheet metal industry and with a long history of producing innovative and reliable press brake machines, the new HG range is eagerly anticipated. Featuring a patented hybrid drive system and a new ‘Smartphone style' 3D control unit, the HG is the fastest and most accurate press brake within the Amada range.

• Hybrid Drive System - ecological & high accuracy
• High accuracy bending - beam adjusts during part processing
• Multi touch screen 3D control - 19" smartphone style
• Tool clamping -  S Grip, Wila or Pneumatic
• BiS or BiL automatic angle measuring system options

Benefits

Reduced Power & Maintenance

• Hybrid Drive – electric servo driven hydraulics
• Ecological - 50% power saving and 60% less oil

High Speed Operation

• 20mm/s bend speed and 220 mm/s approach

High Precision Operation

• Positioning accuracy of 0.001mm
• Beam adjusts during part processing
• Automatic material thickness detection
• BI-S or BI-L automatic angle measurement system options

Fast & Easy Part Processing

• Multi CNC controlled axis
• Multi touch screen 3D control
• BendNavi control software – input DXF files to control
• Automatic sliding foot pedal (option)
• L-Shift backgauge for complex part gauging (option)
• Wireless DIGIPRO

Fast & Secure Tool Clamping

• Amada A Grip-M tool clamps
• S-Grip/Wila/Pneumatic options

CADCAM Software Solution Pack

• Production Designer – accurate processing of 2D & 3D files
• Dr ABEII – automated offline programming

Bending Solution Pack Options

• Sheet followers
