LU300

• Main spindle motor, VAC 15/11kW (10min./cont)
• Main spindle speed, max. 8,000min-1
• Rapid traverse in X/Y/Z-axis: 60m/min
• Cutting feedrate in X/Y/Z-axis: Max. 60m/min
• Table 1degree indexing
• 40-tool ATC instead of 30-tool ATC (domestic standard)
• Tool pull stud bolt standard: MAS BT40 / JIS Through Pull stud
• ATC air blower
• Tool release lever (BT40)
• Spindle taper hole cleaning rod
• Hand tools
• Spindle cooling system
• Max acceleration in rapid traverse: 0.7G
• Spindle-through-coolant supply system, 15kg/cm2
• Chip air blower, nozzle type
• Work light, halogen lamp
• Internal chip conveyor
• Chip pan
• Two-layer signal tour (Blue; operation end lamp / Yellow; Alarm lamp)
• Foundation washers
• Totally enclosed guard
• 2-pallet swivel type APC (with two sets of MAS pallets)
• CE Mark and EMC
• IEC standard
• OSP-P300M CNC Controller

Electrical Power Source Application to suite local power source at each countries (CE transformer)

* All the specifications indicated in this specs are subject to change without prior notice
